Elevate your interior space with our premium Indoor LED Screen series, display solutions engineered to captivate and engage. Ideal for enhancing retail stores, corporate lobbies, conferences, and entertainment venues, these displays deliver sharp, vibrant imagery from any viewing angle. Designed for seamless integration and long-term reliability, this energy-efficient product line provides a stunning visual experience to leave a lasting impression on your audience.
GET A QUOTE
FEATURES
PRODUCT SPECS
PROJECT
FAQS
Energy-efficient; 50-60% energy saving.
Less than 25kg/㎡, the thinnest panel can reach 38mm.
No need complicated steel structure to place the screen, easy installation for stacking or wall-mounted.
P0.9375 / P1.25 / P1.667 / P1.86 / P2 / P2.5 Led Module & Panels & Screens available.
All-in-one LED panel allows for the individual replacement of key components—such as a single module, power supply, or receiving card—directly from the front, without removing the entire panel.
Advertising fixed installation, adding flying bar, connectors and fast lock for rental, adding rubber cushion and bracket for perimeter display.
A flexible LED screen is made up of LED pixels pitched on a pliable material like rubber or PCB. It is insulated using a flexible transparent material on both sides to protect the LED circuit from getting damaged. This structure makes flexible LED screens highly resilient.
Vision Pro's Flexible led display VPF series that are tailor-made to fit in your space and captivate audiences. Whether it’s a 3D gaming lounge or a conference, you can rely on our flexible LED screens to deliver high-resolution images at all times. They are available in different dimensions and pixel pitch options depending on your needs.
VPF Series Specifications
| Items | VPF-0.9 | VPF-1.2 | VPF-1.5 | VPF-1.8 | VPF-2 | VPF-2.5 |
| Pixel Pitch (mm) | 0.9375 | 1.25 | 1.579 | 1.875 | 2 | 2.5 |
| LED | Mini 4in1 | SMD1010 | SMD1212 | SMD1515 | SMD1515 | SMD2020 |
| Module Size | 240mmX120mm | |||||
| Module Resolution | 256*128 | 192*96 | 152*76 | 128*64 | 120*60 | 96*48 |
| Cabinet Size | Diameter customized, size Customized | |||||
| Cabinet Materails | Metal or Die-casting Aluminum | |||||
| Brightness | 600-1300 nits | |||||
| Refresh Rate | 3840HZ | |||||
| Maintenance | Front&Rear | |||||
Download Flexible LED Video Wall PDF
Learn MoreHD Series offers the highest definition LED video wall solutions, suitable for the most demanding applications where a narrow pixel pitch is a need in a fixed installation environment such as TV broadcasting studios, traffic control rooms, boardrooms, etc. The sleek and seamless high definition led displays to deliver a superb visual performance with high refresh rate, excellet greyscale levels, high contrast and wide colour gamut.
Small Pixel Pitch LED Screen Specifications
| Items | HD09 | HD12 | HD15 | HD18 |
| Pixel Pitch (mm) | 0.937mm | 1.25mm | 1.56mm | 1.875mm |
| Pixel Density (dot/㎡) | 1137770 | 640000 | 409600 | 284444 |
| Brightness | 500-800 nits | 500-800 nits | 500-800 nits | 500-800 nits |
| Module Resolution | 320X180 | 240X135 | 192X108 | 160X90 |
| Refresh Rate | 3840HZ | |||
| Cabinet Materials | Die casting Aluminum | |||
| Application | Indoor | |||
TZ Series is a high-tech product with high transparency and brightness that is installed behind the beams of a glass facade. This product is the perfect solution for breathing new life into glass facades, show rooms, exhibitions, shopping malls, museums, retail advertising, commercial sapces, indoor decoration and many more applications.
Transparent LED Screen Specifications
| Items | TZ-2 | TZ-3 | TZ-7 | TZ-10 |
| Pixel Pitch (mm) | P2.6-5.2 | P3.91-P7.82 | P7.82-P7.82 | P10.4-P10.4 |
| Pixel Density (dot/㎡) | 73728 | 32768 | 16384 | 9216 |
| Brightness | 1000-5500nits, customized | |||
| Transparency | 55% | 65% | 70% | 80% |
| Refresh Rate | 1920HZ or 3840HZ | |||
| Cabinet Materials | Die Casting Aluminum or Aluminum Alloy | |||
| Application | Glass Wall, Glass Window, Retail Shop, Indoor Mall | |||
Our VPU series is designed specifically for indoor fixed led wall markets, this panel are light weight and slim but durable, equiped with user-friendly feartures like full front maintenance, no frame installation design
| Items | VPU-1.8 | VPU-2.2 | VPU-2.5 | VPU-2.6 |
| Pixel Pitch (mm) | 1.83 | 2.23 | 2.5 | 2.6 |
| LED | SMD1515 | SMD1515 | SMD1515 | SMD2020 |
| Pixel Density (dot/㎡) | 295936 | 201100 | 160000 | 147456 |
| Module size (mm) | 250x250 | |||
| Module Resolution | 136x136 | 112x112 | 100x100 | 96x96 |
| Cabinet size (mm) | 1250mmx250mm; 1000X250mm; 750mmX250mm; | |||
| Cabinet Materials | Aluminum | |||
| Thickness | 38mm | |||
| Scanning | 1/34 | 1/28 | 1/25 | 1/24 |
| Cabinet Flatness (mm) | ≤0.1 | |||
| Grey Rating | 14 bits | |||
| Application environment | Indoor | |||
| Protection Level | IP45 | |||
| Maintain Service | Front Access | |||
| Brightness | 800-1200 nits/3000-3500 nits | |||
| Frame Frequency | 50/60HZ | |||
| Refresh Rate | 3840-7680HZ | |||
| Power Consumption | MAX: 600Watt/sqm; Average: 200Watt/sqm | |||
VisionLedPro's Indoor LED Display series comprises high-resolution systems built from fine-pitch LED modules, creating seamless and scalable viewing surfaces. Tailored for diverse indoor applications—including broadcast studios, control rooms, and corporate halls—they ensure exceptional color accuracy and brightness even in well-lit environments. Key technical features include ultra-wide viewing angles, low power consumption, silent operation, and a modular design for flexible configurations and easy maintenance. This product family offers a dynamic and immersive medium to communicate effectively and foster a modern, professional atmosphere.
This project entails installing a state-of-the-art indoor LED display (Model HD-15) in the United States. With its fine pixel pitch and dimensions of 5400x1687.5mm, this LED screen delivers exceptional image quality perfect for close-viewing indoor applications such as corporate lobbies, control rooms, and conference halls. The display's slim profile, front-serviceable design, and intelligent monitoring system ensure both stunning visual performance and straightforward maintenance, creating an engaging viewer experience that will enhance client engagement and deliver strong investment returns.
Discover the Project
The ideal viewing distance depends primarily on the pixel pitch (the distance between the centers of two adjacent pixels). A general rule of thumb is: Minimum Viewing Distance: Pixel Pitch (mm) × 1.6 (for a detailed image) and Recommended Viewing Distance: Pixel Pitch (mm) × 3.3 to 8 (for a comfortable balance of detail and overall picture). For example, a P2.5 display (2.5mm pixel pitch) is best viewed from approximately 8 feet (2.5m) and beyond.
Pixel pitch is the most critical specification for indoor displays. It measures the density of pixels and directly determines the image's sharpness. A smaller pixel pitch means pixels are closer together, resulting in a higher resolution and a sharper image at closer viewing distances. For boardrooms and retail, a finer pitch (e.g., P1.2 - P2.5) is standard.
1) Mount: Attach a lightweight frame to your wall. 2) Snap: Lock the lightweight LED panels onto the frame like building blocks. 3) Connect: Plug in the single power and data cables. 4) Play: Turn it on and your content is ready to display.
Modern indoor LED panels are designed for front-serviceability. This means all critical components—including individual LED modules, power supplies, and receiving cards—are hot-swappable. Technicians can safely remove and replace any faulty part directly from the front of the display without needing to access the rear, making maintenance quick and easy.
Absolutely. Indoor LED panels are inherently modular. They can be configured into a wide variety of sizes and standard aspect ratios (like 16:9). Furthermore, we can offer creative options for non-standard shapes, including columns, curves, and even 3D installations to create a unique visual impact.
Our LED displays are highly versatile. They can showcase a wide range of content, from live video feeds and broadcast signals to dynamic PowerPoint presentations, websites, social media walls, and scheduled image/video playlists. They are compatible with most standard media players and content management systems.
A high-quality indoor LED display has a typical lifespan of 100,000 hours. Brightness for indoor displays is measured in nits (cd/m²). Unlike outdoor displays that require high brightness (5,000+ nits) to combat sun, indoor displays are optimized for comfort, typically ranging from 800 to 1,500 nits to provide a brilliant image without causing eye strain.
if you need further information, a pricing quote, orwant to discuss ideas for using our indoor LED Display click the link below to contact us
